Simplified diagram of the rod set split of the sieving mechanism

　　Unfortunately, due to the limitations of the textual description, I am unable to provide you with an image, but I can provide you with a textually illustrated sketch that will help you understand the way the bar set of a sieve mechanism comes apart.

　　The bar set of a screen mechanism usually consists of the following main parts: upper cross bar, lower cross bar, longitudinal bar and connectors.

　　1. Upper crossbar: Located at the top of the sieve mechanism, parallel to the sieve surface, it is the main support part of the sieve mechanism.

　　2. lower crossbar: located at the bottom of the sieve mechanism, parallel to the upper crossbar, it is also an important support part of the sieve mechanism.

　　3. longitudinal bars: vertical bars connecting the upper and lower bars, the number and position of the longitudinal bars depends on the specific design of the screening mechanism, usually, the longitudinal bars are evenly distributed between the upper and lower bars.

　　4. Connectors: elements used to connect the upper and lower cross bars to the vertical bars. The connectors are usually bolts and nuts, which are fastened to ensure the stability of the screening mechanism.

　　Sifter

　　Rod set disassembly refers to breaking down the rod set of the screen media mechanism into separate components for installation, maintenance or replacement, the following is a simple way of disassembly:

　　1. Remove the connecting parts: first, use a tool such as a spanner or spanner to remove the connecting parts and separate the upper cross bar from the longitudinal bar and the lower cross bar.

　　2. Separate the longitudinal bar: remove the longitudinal bar from the upper crossbar and lower crossbar, making sure that the connection between the longitudinal bar and the crossbar will be broken.

　　3. Disassemble the cross bars: remove the upper and lower cross bars from the support frame of the screening mechanism, making sure that the connection between the cross bars and the support frame will be broken.

　　The above steps give the basic process of dismantling the bar set, the exact dismantling method may vary depending on the design and structure of the sieving mechanism, when operating, please make sure to follow the relevant safety regulations and adjust them according to the actual needs.

　　We hope that this written description will be helpful to you!
